Control Upgrades

Our Clients Describe the Following Problems with Their Obsolete Technology

• Increased costs to maintain
• Loss of support for old hardware and software
• Risk of production loss; if a component fails, it takes a long time to get a replacement or find people who know how to configure it
• Inability to improve the system. Programming is difficult, so changes are avoided. The old system does not have capabilities for data handling that can improve production.
• Potentially limited system speed due to control system capabilities

New software and hardware will have new capability to do things the old system could not.

• Collect performance data for continuous improvement
• Integrate with databases to get information for rapid setup and product changes
• Integrate with upstream or downstream equipment
• Likely uncover and address existing problems that have been slowing production
• Increase machine speeds

APQ will follow a process (below) to design and implement a new system.

Our Goals Include

• Minimizing risk by planning and testing
• Minimizing downtime by designing for fast installation
• Providing a fully documented system for ease of maintenance
• Providing current hardware that will be supported far into the future

Our PLC Upgrades Process

1. Survey existing system
   • IO count
   • Networks
   • Enclosures needed
2. Evaluate options for new control platform
3. Propose a control platform that will be the best fit for functionality and maintenance
4. Identify opportunities for improvements in functionality. Common opportunities include:
   • Data collection
   • Database for line setup
   • Integration with upstream or downstream processes
   • Increased speed
5. Generate detailed quote
6. Project approval
7. Control panel design. We consider the following options to minimize downtime for installation:
   • Replace enclosures
   • Replace subpanels
   • Replace components on existing subpanels
8. Programming
9. Panel construction
10. Simulation and testing
11. Factory Acceptance Testing (testing with the customer before the program leaves APQ)
12. Commissioning

Examples of Conversions

• PLC5 to ControlLogix for a whey dryer
• Siemens to ControlLogix for a new machine from Germany
• Modicon to Omron for a refrigeration compressor room
• Six Modicon controllers converted to a single Allen-Bradley for a cheese plant
• Packaging machine retrofit with new control panels and servo motors
• Retrofit metal fabrication equipment replacing mechanical cams with servo controls
• Convert Labview HMI to Ignition SCADA and MES platform for consumer packaged product.
• Convert Citect to Ignition SCADA and integrate lab information system for food plant.
